1500V AC/Min PA 66 2 Pole Electrical Plug Housing
  • 1500V AC/Min PA 66 2 Pole Electrical Plug Housing

1500V AC/Min PA 66 2 Pole Electrical Plug Housing

Place of Origin China
Brand Name WT
Certification UL、ISO 9001、RoHS
Model Number ELR-04NV
Product Details
Wire To Wire Connector
Male Female Combination
Withstand Voltage:
1500V AC/min
Nylon 66
Voltage Rating:
300V AC,DC
Temperature Range:
High Light:

2 Pole Electrical Plug Housing


PA 66 Electrical Plug Housing


1500V AC/Min Connector Terminal Housing

Payment & Shipping Terms
Get the latest price
Packaging Details
Export Cartons
Delivery Time
3-30 Working Days Based On Your Finally Quantities
Payment Terms
L/C, T/T
Supply Ability
Product Description

2-Pole Electrical Plug Housing Connector Terminal Housing




JST Model No.

Certification UL, ISO 9001, RoHS, REACH
Pitch 4.50mm pitch
Circuits 2--10
Material PA 66
Gender Female
Color Negotiable
Connector type Disconnectable Crimp type, Wire to Wire
Temperature range -25~85
Voltage Rating 300V AC,DC
Current rating 10A AC,DC
Withstand voltage 1500V AC/min
Insulation resistance ≥1000MΩ min
Contact Resistance Initial Value≤0.01Ω
  After Environment Tests ≤0.02Ω
